Your Precision Process Inspection problems solved

INCOMING     |     PCBA     |      FINAL Q.C.
find out more
% SYSTEM UP TIME
PERCENT
LESS THAN
% FALSE CALLS
PCBA THROUGHPUT >
BOARDS PER DAY

THE RESULT FOR YOU


Find more PCBA manufacturing faults in less time with a3Di

The a3Di is not a 3D AOI (Automated Optical Inspection) system. It is a revolutionary laser based metrology measurement system that enables you to find faults on your populated PCBAs like never before. The extremely accurate measurement capabilities of under a micron resolution in the Z axis will give you the confidence that if there is an issue on your PCBA, a3Di will find it.

When your 2D or 3D AOI system  doesn't deliver, a3Di will

Find manufacturing issues such as board warp, device co-planarity, foreign objects, pin height, solder joint and coating issues that affect the reliability of your product. a3Di will help lower the risk of field failures and expensive recall events that could negatively affect your brands reputation.

Kick false calls into touch!

a3Di does not use comparison techniques like traditional 2D and 3D AOI systems. It takes absolute metrology quality 3D measurements across the whole of the PCB assembly. No area is left unmeasured. These measurements are then referenced to the original CAD data meaning that if a fault is found it is a REAL fault. The result is that no subjective operator input is required as there are NO false calls or testing delays.

Quality processes start with accurate inspections.

The a3Di provides extensive process data to feed an SPC system the information required to quickly verify and validate that your assembly operations can pass a customer quality audit with minimal data collection effort.

Why choose a3Di?

  • Improves your PCB assembly inspection integrity, manufacturing quality & brand reputation
  • Improves product yield and reduces harmful recall events
  • Increases product throughput, reduces set up time and cost
  • Cost effective & robust alternative to 2D & 3D AOI systems
  • Performs accurate 3D physical measurements at high speed
  • Near zero false call rate = no operator required
  • Provides real-time SPC to debug real board faults
find out more about a3di

     Request your copy of the a3Di brochure now

Request your brochure now

a3Di - When PCBA inspection quality matters to you, it matters to us

Contact us to discuss your PCBA inspection challenges

contact us

Join our mailing list to receive the latest updates on a3Di

Join Now
Download the a3Di short form flyer now
download
